ALL COMPONENTS

FRAME SET

FRAME

TorayCa M40X, TiCR™ Cable Routing, Italian BB

FORK

NEW eTICR Onda Fork with ForkFlap™, 1.5′ upper and lower steerer

WEIGHT

6.77kg. Weight in size 53, Shimano Dura Ace, Princeton Peak 4550 wheels, w/o pedals and w/o bottles

DRIVETRAIN

CRANKSET AND CHAINRINGS

Shimano Dura Ace FC-R9200, HollowTech 2, 12s

FRONT DERAILLEUR

Shimano Dura Ace Di2 FD-9200 12S

REAR DERAILLEUR

Shimano Dura Ace Di2 RD-R9200 12s

CASSETTE

Shimano Dura Ace CS-R9200 12S

CHAIN

Shimano Dura Ace CN-HG 12S

BOTTOM BRACKET

Shimano Dura Ace SM-BB9200

BRAKES

FRONT BRAKE DISC

Dura Ace BR-R9200, 2 pistons caliper, 160mm rotor

REAR BRAKE DISC

Dura Ace BR-R9200, 2 pistons caliper, 140mm rotor

COCKPIT

INTEGRATED HANDLEBAR

MOST Talon Ultra Fast

BAR TAPE

most bar tape

SADDLE

Most Lynx Ultrafast Superflow L Carbon Large 145mm

SEATPOST

Pinarello Aero seatpost with 3D printed titanium top seatclamp and bolts

WHEELS AND TIRES

TYRES DISC

Continental Gran Prix 5000S TR28-622

WHEELSET DISC

DTSWISS ARC 1400

AXLES DISC

NEW MOST Ultra Light Custom Axle 12×100 & 12×142, tool free removal

Geometries

CE	CC	L	A [°]	B [°]	P	T	D	R	G	REACH	STACK
425	430	500	74.4	69.5	407	102	67	47	373	351.5	502
450	465	515	74.4	70.5	407	109	72	47	373	365.4	517.3
465	500	525	74	71.4	407	114	72	47	373	372.2	525.2
485	515	535	73.7	72	407	119	72	47	373	378.2	532.1
500	530	545	73.7	72.5	407	128	72	47	373	383.3	542.4
510	540	550	73.4	72.8	408	136	72	47	373	385.3	551
520	550	557	73.4	72.8	408	147	72	47	373	389.2	561.5
525	560	565	73	73.2	409	154.5	72	47	373	390.8	570.1
540	575	575	73	73.7	409	168	72	47	373	396.7	584.8
560	595	587	72.4	73.4	409	204	67	47	373	393.4	613.2
600	620	620	72	73.4	411	244	67	47	373	410	651.6
