The new generation of Grevil F is lighter, faster, and designed to be ridden for days on end. No matter the conditions or the duration of the race, the bike’s versatility provides the perfect solution to help you compete to win.

Geometries

CF	CC	L	I	A[°]	B[°]	F	P	T	D	R	G	WB	REACH	STACK
410	470	530	125.6	74.5	70.25	603.9	430	115	72	55	405	1023.5	368.4	553.2
440	500	545	137.8	74	70.5	614.5	430	130	72	55	405	1034.2	376.1	568.3
470	530	558	148.3	73.75	70.75	625.8	430	150	67	55	405	1047	383.7	583.2
490	550	570	156.2	73.5	71.75	621.9	430	160	67	50	405	1043	390.4	598.4
510	575	587	168.1	73	72	631.9	430	175	67	50	405	1053.1	398.2	613.6
545	600	607	180.4	72.5	72.25	644.3	430	195	67	50	405	1065.5	406.9	633.7

CE: SEAT TUBE CENTER – END, CC: SEAT TUBE CENTER – CENTER, L: TOP TUBE CENTER – CENTER, A[°]: SEAT TUBE ANGLE, B[°]: HEADTUBE ANGLE, P: CHAINSTAY, T: HEADTUBE, D: BB DROP, R: FORK RAKE , G: FORK HEIGHT, REACH, STACK

ALL COMPONENTS

FRAME SET

FRAME

TORAY T700 UD

FORK

F Onda Fork with ForkFlap™, Tapered head tube

DRIVETRAIN

CRANKSET AND CHAINRINGS

SHIMANO GRX 820 2×12

CASSETTE

SHIMANO GRX

CHAIN

SHIMANO GRX

BOTTOM BRACKET

SHIMANO DURA ACE BB-R9100 70mm

BRAKES

FRONT BRAKE DISC

Shimano GRX, 2 pistons caliper, 160mm rotor

REAR BRAKE DISC

Shimano GRX, 2 pistons caliper, 160mm rotor

COCKPIT

HANDLEBAR

JAGUAR XA GR TICR

STEM

TIGER ALU AERO TICR

BAR TAPE

Bar Tape MOST Ultragrip evo 3mm – Black

SADDLE

Most Lynx My26

SEATPOST

D-SHAPE SEATPOST

SEAT CLAMP

classic seat clamp

WHEELS AND TIRES

TYRES DISC

VITTORIA TERRENO T50 45

WHEELSET DISC

FULCRUM SONIQ AL*

AXLES DISC

NEW MOST Ultra Light Custom Axle 12×100 & 12×142, tool free removal
